BH77 fitment

[Walter C.]

Will the sub frame from my BH77 backhoe that is on my 2015 L3901 fit on a 2019 L3560?



[dirtydeed]

I'd doubt it. I thought that the L3560 has a larger frame than the L'01 series. It also call for the BH92 backhoe, not the BH77. I would expect the 4 pt connection would be different widths.



[wgator]

The KubotaUSA web site says the L3560 can use the BH77 or BH92, but with that said, see attached excerpts of sub frame kits from the BH77 install manual for the L3560 and the L3901. They have different kit numbers.



[dirtydeed]

That's interesting that it can use the BH77. If that's the case, you'd likely just have to get the sub-frame kit.

I saw somewhere that that tractor took a BH92 (but i think that was with a specific loader model).



[wgator]

A update to my previous post. From the L3560 brochure:
The BH77 is compatible with the Grand L3560 ROPS models only.
The BH92 is compatible with the Grand L ROPS and Cab models. The L3560 model must be equipped with LA805 loader to install BH92 backhoe. (Cannot be installed with LA555 loader.)



[ArtinAz]

The KubotaUSA web site says the L3560 can use the BH77 or BH92, but with that said, see attached excerpts of sub frame kits from the BH77 install manual for the L3560 and the L3901. They have different kit numbers.
View attachment 45019
View attachment 45020

I'm getting ready to build my shed for tractor & implements. How much room should I reserve for the bh77?



[Nicfin36]

I'm getting ready to build my shed for tractor & implements. How much room should I reserve for the bh77?

I have a L2501. I'm sure measurements are almost or exactly the same. I measured for you. It sticks out about 6 feet when holding the tape measure against the tire and measuring to the back pivot on the bucket.
